Forge Motorsport coilover kit for Tesla Model 3/Model Y

The kit lowers the vehicle by approximately 30 mm.

Developed and tested by Forge Motorsport in collaboration with electric vehicle specialists Cleevely EV, this coilover kit provides a balanced combination of performance and comfort. With 32 damping adjustment settings, it can be tailored to your preferences for road or track driving. Compression and rebound are adjusted simultaneously.

• The front dampers feature Pillowball top mounts for camber adjustment.
• Manufactured from 52 mm diameter seamless carbon steel tubing, compliant with JIS G3445 and DIN2393 standards.
• The 44 mm diameter linear-action internal piston provides optimal damping response for the tube diameter.
• High-quality monotube damper design.
• High-viscosity oil ensures efficient damper operation.
• The damper length is adjustable, so the spring seat does not need to be adjusted as with conventional coilovers. This ensures the maximum possible damper travel.
• Cold-drawn springs are manufactured from high-strength steel in accordance with SAE9252.

Suitable for: Tesla Model 3 I (5YJ3), Tesla Model Y I (5YJY).

Approval

This part has no TÜV certification (ABE, TTG or Teilegutachten).

Compatible vehicles (manufacturer data)

Before ordering, check that the product matches your vehicle (model, year and engine). If in doubt, write to us — we will check for you.
