ACL Race rod bearings for Mazda L3

ACL Race rod bearings for Mazda L3 combine trimetal construction, metallurgy and engineering for demanding high-RPM conditions.

The set is designed to improve bearing lining support, bearing retention in the housing, heat transfer and oil flow.

• High-strength overlay plate with reduced thickness for improved fatigue properties
• Hardened steel backs on all rod bearings
• Increased crush for improved bearing retention in the housing
• Increased eccentricity to compensate for bore distortion at high RPM
• 3/4-grooved main bearings to optimize bearing load-carrying surface area and oil flow to the rod bearings

Suitable for: Mazda 3 I (BK), Mazda Tribute I.

Engines: L3 (L3MZR). Please check your vehicle’s engine code (registration document or VIN) before ordering; if in doubt, contact us and we will check for you.

Sizes

STD is the standard size for an unground crankshaft. Undersizes (−0.25 mm, −0.50 mm …) are for a reground crank, and “+0.025 mm clearance” (X) is for highly stressed engines. Your machine shop chooses the size after measuring.
