ZRP forged pistons for Mitsubishi EVO 4-9 4G63

ZRP 1400HD forged pistons are designed for the 2.0-litre Mitsubishi 4G63 engine in EVO 4–9 models. The product name also references the Wiseco brand.

The pistons are made from 2618 alloy with low silicon content and high thermal expansion. They are available in the three diameters listed; when choosing, the actual cylinder measurement and required clearance must be taken into account.

Specifications

• Engine: 2.0L 4G63
• Application: Mitsubishi EVO 1–9 or EVO 4–9
• Piston diameter: 85.00 mm, 85.25 mm or 85.50 mm
• Crankshaft stroke: 88.00 mm
• Connecting rod length: 156.00 mm
• Material: 2618 alloy with low silicon content and high thermal expansion
• Stated compression ratios: 9.0:1 / 8.52:1 and 8.8:1

Suitable for: Mitsubishi Eclipse I (D2) / II (D3/A), Mitsubishi Galant IV (A16) / V (E1A) / VI (E39A) / VII (E5/E7/E8) / VIII (EA), Mitsubishi L200 III (K60/K70), Mitsubishi L300 II / III (P0V/P1V/P2V), Mitsubishi L400 I (PD/PC/PB/PA), Mitsubishi Lancer VII (CS/A), Mitsubishi Outlander I (CU/W), Mitsubishi Space Runner I (N1/N2) / II (N6), Mitsubishi Space Wagon I (D0) / II (N30) / III (N50), Mitsubishi Tredia I (A21).
