ZRP Diamond forged piston kit for the Mitsubishi EVO X 2.0L 4B11 engine. The pistons have a compression ratio of 9.7:1 and are made from 2618 material, while H-13 tool steel pins are included.
The supplier also specifies a 94.00 mm crank measurement and a piston dish volume of −12.0 cm³. All measurements and specifications must be checked against the specific engine configuration before installation.
Technical data
- Engine: 2.0L 4B11
- Variant: Mitsubishi EVO X
- Compression ratio: 9.7:1
- Material: 2618
- Diameter: 90.00 mm
- Stated crank measurement: 94.00 mm
- Dish volume: −12.0 cm³
- Piston ring dimensions: 1.0 mm × 1.2 mm × 2.8 mm
- Pin measurement: 143.71 mm
- Part number: H9052250200C
Suitable for: Mitsubishi Lancer VIII (CY/A).
