ZRP forged pistons for Mitsubishi Lancer VIII (Evo X) 2.0 4B11

ZRP Diamond Forged pistons for the Mitsubishi 2.0 4B11 engine in the Lancer Evo X. The pistons are made from 2618 aluminium alloy and equipped with H-13 tool steel pins.

Supplier data specifies a compression ratio of 10.1:1, a piston diameter of 90.00 mm, a piston dish volume of −15.0 cm³ and a 98.00 mm crankshaft. The dimensions must be checked against the specific engine configuration before installation.

• Engine: 2.0L 4B11
• Piston diameter: 90.00 mm
• Compression ratio: 10.1:1
• Material: 2618
• Pins: H-13 tool steel
• Piston ring dimensions: 1.0 mm × 1.2 mm × 2.8 mm
• Piston dish: −15.0 cm³
• Additional dimensions listed in the data: 143.71 mm and 27.18 mm
• Part number: H9052250200C
• SKU: 82066-4-H

Suitable for: Mitsubishi Lancer VIII (CY/A).
