ACL Race Series are trimetal rod bearings designed for higher loads and high-RPM conditions. Their combination of design, metallurgy and engineering supports stable bearing surface operation.
The set includes ACL Race Series rod bearings. Increased eccentricity assists in forming hydrodynamic oil films, while tight and consistent wall tolerances help maintain consistent clearances.
- High-strength overlay plate with reduced thickness
- Hardened steel backs on all rod bearings for improved lining support and retention in the housing
- Increased crush for improved bearing retention
- Elimination of flash plating on the back for improved heat transfer and increased grip in the housing
- Increased eccentricity to compensate for bore distortion at high RPM
- Tight, consistent wall tolerances
Suitable for: Ford Mondeo III (B4Y) / III (B5Y) / III (BWY) / IV (BA7), Ford Ranger III (2AB) / IV (TKE), Ford Tourneo I (V184/V185), Ford Transit V (FD/FB/FS/FZ/FC) / VII (FM/FN/FF), Jaguar X-Type I (X400).
Engines: Duratorq 2.0, Duratorq 2.4, 2.0 TDCi, Duratorq 2.2, P4 (AZBA, D5BA, D6BA, FMBA, HJBA, HJBB, HJBC, N7BA, N7BB, SDBA, LPBA, P4-AT, ABFA, D3FA, F3FA, FIFA, D2FA, D2FB, D4FA, DOFA, F4FA, D2FE). Please check your vehicle’s engine code (registration document or VIN) before ordering; if in doubt, contact us and we will check for you.
Sizes
STD is the standard size for an unground crankshaft. Undersizes (−0.25 mm, −0.50 mm …) are for a reground crank, and “+0.025 mm clearance” (X) is for highly stressed engines. Your machine shop chooses the size after measuring.
