Important: This product is not compatible with the original intercooler. It can only be used with an aftermarket intercooler that has a 63–67 mm diameter outlet on the cold side. It works perfectly with the Forge FMINT15 intercooler.
The boost pipe runs from the intercooler outlet to the intake manifold. There was room for improvement in the original pipe, so a 70 mm aluminium pipe with mandrel bends and silicone couplers was developed.
CNC-machined fittings made from aluminium billet are integrated into the pipe, allowing all original mounting hardware to be used. Compared with the original pipe, the diameter of the flow channel is increased from 51 mm to an outside diameter of 70 mm. The larger diameter allows improved airflow and a greater volume of air entering the engine, which is particularly beneficial for vehicles with modified software.
The pipe also features a 1/8″ port for injecting a water-methanol mixture or nitrous oxide. This makes it possible to reduce intake air temperature when loading the 2.0-litre Hyundai engine.
- Available in a durable black powder-coated or raw aluminium finish.
- Minimal restriction to airflow.
- Larger diameter for improved flow compared with the original pipe.
- One-piece aluminium pipe with mandrel bends.
- CNC-machined fittings made from aluminium billet.
- Forge silicone hoses have an inner lining made from modified fluorosilicone, making them suitable for use with long-life coolants, O.A.T.-technology-based coolants or air containing oil mist.
- Designed to operate without an engine management light (EML).
Suitable for: Hyundai I30 III (PD), Hyundai Veloster II (JS).
Compatible vehicles (manufacturer data)
| Vehicle | Chassis | Years | Engine |
|---|---|---|---|
| Hyundai i30 | MK3 | 2017–2020 | — |
| Hyundai Veloster | — | 2019–2020 | N T-GDI (Pre-Facelift) |
Before ordering, check that the product matches your vehicle (model, year and engine). If in doubt, write to us — we will check for you.
