ACL Race rod bearings for Mitsubishi 6G72 / Sigma 3.0 V6 / Sigma 2.5 V6 …

ACL Race Series rod bearings are trimetal bearings developed for demanding operating conditions and higher engine RPM. Their combination of design, metallurgy and engineering supports high-performance engine applications.

The set includes ACL Race Series rod bearings with features designed to improve retention in the housing, heat transfer and the formation of a stable hydrodynamic oil film.

• High-strength overlay plate with reduced thickness for improved fatigue properties.
• Hardened steel backs for improved support of the bearing lining and bearing retention in the housing.
• Increased crush for improved bearing retention.
• Eliminated flash plating on the back for improved heat transfer and increased grip between the bearing and its housing.
• Increased eccentricity to compensate for bore distortion at high RPM and assist in forming hydrodynamic oil films.

Suitable for: Hyundai Galloper I, Hyundai Sonata II (Y2) / III (EF) / III (Y3), Mitsubishi 3000 GT I (Z1/A), Mitsubishi Delica III (P25W/P35W), Mitsubishi Diamante I (F1/A/F2/A/F3/A), Mitsubishi Eclipse III (D5), Mitsubishi Galant V (E1A) / VII (E5/E7/E8) / VIII (EA), Mitsubishi Grandis I (NA/W), Mitsubishi L200 III (K60/K70), Mitsubishi L300 III (P0V/P1V/P2V), Mitsubishi Magna I (TE/TF/TH/TJ/TL/TW), Mitsubishi Pajero Sport I (K90), Mitsubishi Pajero I / II (V20) / III (V60/V70), Mitsubishi Sigma I (F0/W), Mitsubishi Space Wagon III (N50), Mitsubishi Verada I (KE/KF/KH/KJ/KL).

Engines: 6G72, Sigma 3.0 V6, Sigma 2.5 V6, 6G73, G6AT (G6AV, 6G72, G6AT, 6G72-T, 6G73). Please check your vehicle’s engine code (registration document or VIN) before ordering; if in doubt, contact us and we will check for you.

Sizes

STD is the standard size for an unground crankshaft. Undersizes (−0.25 mm, −0.50 mm …) are for a reground crank, and “+0.025 mm clearance” (X) is for highly stressed engines. Your machine shop chooses the size after measuring.
