ACL Race main bearings for BMW S85

ACL Race main bearings for BMW S85 are tri-metal engine bearings designed for higher RPM conditions. The combination of construction, metallurgy and engineering improves fatigue resistance and bearing retention in the housing.

3/4 grooving optimizes the main bearing load-carrying surface area and oil flow to the conrod bearings. Increased eccentricity helps compensate for bore distortion at high RPM and assists in forming hydrodynamic oil films.

• Tri-metal construction with a high-strength overlay plate of reduced thickness
• 3/4 grooving for optimized load-carrying surface area and oil flow
• Increased eccentricity to compensate for bore distortion
• Tight, consistent wall tolerances for consistent clearances
• Enlarged ID chamfers for large fillet radii on performance crankshafts
• Main bearing set with 0.025 mm extra clearance

Suitable for: BMW 5 V (E60/E61), BMW 6 II (E63/E64).

Engines: S85 (S85B50A, S85B50). Please check your vehicle’s engine code (registration document or VIN) before ordering; if in doubt, contact us and we will check for you.

Sizes

STD is the standard size for an unground crankshaft. Undersizes (−0.25 mm, −0.50 mm …) are for a reground crank, and “+0.025 mm clearance” (X) is for highly stressed engines. Your machine shop chooses the size after measuring.
